  • Pfeil Description

    VARIO-HP Classic

    The flexible drinking water filter offers convenience at an affordable price and easy connection under the sink.

    scope

    Undersink filter for producing purified drinking water in the kitchen, even in areas with high lead and copper concentrations. The device is installed under the sink between the angle valve and the included tap. A separate, elegant tap is provided for dispensing filtered water ( model WS1-08 ).

    Also suitable for use in front of pressureless boilers. Exclusive and protected housing made in Germany. Each housing is marked with its manufacturing date, facilitating ongoing quality control. The filter can be changed easily using the device key.

    installation

    • for branching from the cold water pipe to separate drinking water extraction
    • with separate tap model WS1-08
    • Also suitable for operation in front of a pressureless boiler

    Attention - important information!

    • For technical reasons, use is only permitted with cold water
    • Only original Carbonit replacement cartridges offer a functional guarantee
    • protect from frost

    Wet filter systems cannot be returned for hygienic reasons and are excluded from the statutory right of return!

    We offer you a loyalty discount with our filter subscription! Download our subscription form here!

  • Pfeil Technische Daten

    Teilenr.: 120VHP-BS1
    Durchfluss: ca. 2....3 l/min (bei 4 bar, nach 5 Min. Einlaufzeit)
    Filterfeinheit: NFP Premium 0,45 µm
    Maße ohne Anschlüsse: (B x H x T) 123 x 310 x 115mm
    Breite mit Schläuchen: ca. 37cm
    Länge der Flexschläuche:  2 Stück je 80cm
    Gewicht: trocken ca. 2,4kg, nass ca. 3,5kg
    Temperaturbereich: Aus technischen Gründen ist der Einsatz nur bei Kaltwasser zulässig, vor Frost schützen

    Hahn

    Gesamthöhe ab Platte: 29,5 cm
    Höhe ab Platte bis Auslauf Unterkante: 23,0 cm
    Ausladung Auslauf bis Mitte Sockel: 12,0 cm
    Durchmesser Sockelblende: 3,5 cm
    Lochgröße Arbeitsplatte: Ø 1,2cm
    max. Stärke der Arbeitsplatte: 5,5 cm
    Material: Messing verchromt
    Ventil-Kartusche: keramisch
    Anschlussgewinde: 7/16'-24 UNS und 3/8' AG

    Die Einzelkomponenten sind entsprechend den Richtlinien des DVGW sowie der DIN EN 14898 überprüft und aus lebensmitteltauglichen Materialien gefertigt. Alle Gehäusematerialien erfüllen die KTW-Empfehlungen und Positivlisten durch hochwertige Kunststoffe (Kopf & Überwurfmutter: GRIVORY GV-4 FWA grau 9442, Tasse: Grilamid TR 90). Die Sicherheitsprüfungen auf Druckfestigkeit erfüllen die DIN 19632, DIN 14898 und GSO 481.1.022. Obwohl der Einsatz nur im Druckbereich PN 10 erlaubt ist, liegt der getestete Berstdruck bei knapp 90 bar.

    Pfeil Lieferumfang
